STEEL INDUSTRIAL passive RFID tags on metal

STEEL INDUSTRIAL passive RFID tags on metal

Category:

LightPioneer STEEL series is the ultimate Industrial RFID tags engineered for Manufacturing and Production, which is able to work under high temperatures(up to 320℃), Shocks, Chemicals, Pressure, Waterproof,providing consistent reliable performance and durability are critical.

Dimensions (mm) 49.5 x 50 x 11.5
Operating frequency 905-928 MHz

866-868MHz

IC type Impinj R6-P
Memory configuration 126-bit-EPC bits; 32-bit user memory
Functionality Read / write (user programmed)
Read Range

on-metal(2W ERP)

Up to 10M
Operating Temperature -30°C to +85°C
Ambient Temperature -30°C to +320°C

(Constant 6hrs testing under 320℃)

Protection Class  IP68
Mounting System Rivet hole Φ5.0 mm

Epoxy Resin

Data retention 50 years
Warranty (limited) 3 years

Application: High-Temperature Production

Paint Shop

Work-In-Process for manufacturing

Automotive Assembly

RTI Management
